Medidul hook trolley with double side loading
HAW 650/1005/1657 2/4HP Medidul
Product code:
7500801
Key facts
Maximum load per hook 30 kg
Deflector castors
Ø castors mm 100
Product information
Trolley made entirely of high-quality stainless steel, robust, self-supporting and hygienic design. Two tubular frame racks consisting of square tubes with curved corners, outer faces with welded hook pairs for attaching e.g. sterile supplies baskets. Inner surfaces of tube frames fitted with shelf bolts for attaching insert rails or insert frame sets for baskets or 1/2 STE containers. Trolley base made of square tube brackets with curved corners. 4 polyethylene disc bumpers serve as bumpers and protect trolley on all sides as well as building-side walls from being damaged. Trolley runs on 4 swivel casters of which 2 with total locks, with pin fastening.
Technical information
Modular dimension: | 333 mm |
Payload: | 300 kg |
Weight: | 13.545 kg |
Width: | 650 mm |
Depth: | 1005 mm |
Height: | 1657 mm |
Downloads
-
Spec sheet
TypeProduct dataFile typepdf (ca. 1.5 MB)Creation Date25.12.2024 -
Tender specification
TypeProduct dataFile typeText for clipboardCreation Date25.12.2024 -
Hook trolley flyer
TypeBrochures and product informationFile typepdf (2.49 MB)Creation Date7 Jul 2023DescriptionEN, PDF -
Care instructions for stainless steel
TypeOperating and assembly instructionsFile typepdf (0.54 MB)Creation Date30 Nov 2020 -
7500801 DWG drawing
TypeDWG drawingsFile typedwg (0.12 MB)Creation Date15 Oct 2019Protected download for dealers and consultants: Please log in and get in touch with our contact partners with regard to activation if necessary.
Spare parts
LR Poly Rz2/100 mF
P/N 014000059
LR Poly Rz2/100
P/N 014000058
